Product number:

HM 803145/10

Brand:

Product name:

bearing

Structure:

tapered roller bearing

Sizes:

41.275X88.9X29.37/23.02

Replacements:

0009247301 170252R91 454463 7450296 803145/10 hm803145-hm803110

Inquiry Subscribe

d	41.275 mm
D	88.900 mm
T	30.162 mm
B	29.370 mm
C	23.020 mm
r(min.)	0.8 mm
r1(min.)	3.2 mm
Basic load ratings : Cr	124 kN
Basic load ratings : C0r	125 kN
Fatigue load limit : Cu	18.5 kN
Limiting speeds(Grease lub.)	4600 min-1
Limiting speeds(Oil lub.)	6100 min-1
Load center spread : a	26.1 mm
Constant :e	0.55
Axial load factors : Y1	1.10
Axial load factors : Y0	0.60
da	54.0 mm
db	53.0 mm
Da	74.0 mm
Db	85.0 mm
ra(max.)	0.8 mm
rb(max.)	3.2 mm
(Refer.)Mass	0.895 kg
